This is the latest designed with 22 Antennas all-in-one for mobile phone 5GLTE GSM 3G 4GLTE signals which bring us a strong jamming ability. And it can not only cut off all 5G 3G 4G mobile phone signals, but also jam Wi-Fi2.4G/5GHz GPS LOJACK, RF 315 MHz 433MHz , VHF UHF Walkie-Talkie & Wireless Headset/Microphone signals. Full bands jammer is power full to blocks all the signals, Jamming frequencies the jamming radius up to 40meters
Advantages:Full bands 22 chancel design, Customized for special frequency range High output power, Total up to: 45W , jamming up to 40m (Still depends on the strength signal in given area) External Omni-directional antennas all the TX frequency covered down link only With Car storage battery Charger DC12V can be used in car Built-in good cooling system inside, Working non-stopped Can adjust or turn off any single band without influencing the other bands operation
| Model | A22 |
| Jamming frequencies |
CDMA/RC868:850-894MHz GSM/LORA:900-960MHZ DCS/PCS:1805-1990MHZ 3G, UMTS:2110-2180MHZ 4G700:700-803MHZ 4G2600:2496-2690MHZ 4G1700:1710-1780MHZ 4G2300:2345-2400MHZ 5G 600:617-675MHZ 5G 3.4G:3300-3600MHZ 5G 3.8G:3600-3900MHZ 5G 4.0G:3900-4200MHZ WIFI 2.4G 11.b, g:2400-2500MHZ WIFI 5.2G 11.a:4900-5500MHZ WIFI 5.8G 11.a:5500-5900MHZ GPS: L1 + Glonass L1:1570-1580Mhz GPSL2+L5 + Glonass L2:1170-1280MHZ GPSL3+L4:1370-1390MHZ Lojack Car Tracking:167-175MHZ VHF:135-175Mhz UHF/RC433:400-470MHZ RC315:315MHZ |
| Power supply | AC adapter 50 to 60Hz, (110 or 220V AC-12V DC) |
| Dimensions | 450x 238x 60mm（not Include Antenna） |
| Net weight | 7kg |
| Total power | 45W |
| Shielding radius | (2-40) meters At -75dBm |
